Automated Guided Forklift

Automated Guided Forklift High Performance & Durable

Automated Guided Forklift

SEER Robotics’ automated guided forklift, featuring an 1180 mm narrow chassis and a robust 2-ton payload capacity, delivers precise high-density stacking and flexible material handling in narrow aisles. As an original equipment manufacturer with a proprietary, independently developed core control system, SEER Robotics eliminates intermediary markups, offering you factory‑direct pricing, rapid digital deployment, and comprehensive, end‑to‑end technical support from the manufacturer.

Automated guided unmanned forklifts are primarily used in high-density vertical automated warehouses, for automated material handling at production lines, for unified scheduling and transportation of multiple vehicle types across different areas, and for the round‑the‑clock automated transfer of large‑item, heavy‑load cargo.

Product Model
SFL-CPD20-Y
Navigation Type
Laser SLAM Navigation
Rated load
2000 kg

Automated Guided Forklift Characteristics

1180 mm narrow body and 2t large load release storage space
The rated load of 2000 kg is realized under the body width of only 1180mm; combined with the extremely small turning radius of 1597mm, the unmanned forklift can travel freely in the right-angle stacking channel, and the cargo space density can be improved without modifying the existing compact warehouse environment.
Laser SLAM navigation to achieve high-precision repeated positioning
Using advanced laser SLAM navigation technology, there is no need to lay magnetic strips or reflectors on the ground. The robot can build a map of the environment in real time and provide navigation position accuracy of up to ± 10 mm, ensuring that the material is accurately in place in the high-precision docking process.
4-layer comprehensive safety protection, short emergency braking distance
Equipped with a 40 m ultra-long detection distance 3D obstacle avoidance laser, safe touch edge, distance sensor, and hardware self-inspection system, braking distance is not more than 50 cm at 1.5 m/s maximum driving speed, providing a 360-degree comprehensive safety barrier for complex man-machine mixed workshops.
Ultrasonic real-time detection of fork disengagement to ensure safe stacking
Built-in advanced ultrasonic detection technology, real-time monitoring of the separation state, and maintains safe spacing between the forks and pallets during high-level or multi-layer cage stacking, effectively preventing the risk of slipping and bumping to ensure the safety of stacking.
The outer width of the fork is adjusted from 400 mm to 700 mm, and the multi-category carrier is intelligently identified
The fork spacing supports flexible adjustment from 400 mm to 700 mm, and the system integrates intelligent vision algorithms, which can independently adapt to accurately identify open pallets, closed pallets, shelves, and material cages of different specifications, greatly improving the compatibility of material handling.
Fast charging and manual power exchange ensure efficient operation
It is equipped with a 24V/200Ah lithium iron phosphate battery with a comprehensive endurance of 6h to 8h. Support automatic and manual charging; 2 h can be quickly filled while supporting inexperienced personnel to complete manual battery replacement within 2 min to ensure uninterrupted operation.
Automated Guided Forklift Structured Detailed Parameter Table
Parameter Classification Parameter name Parameter values ​​/ specifications
Basic parameters Product Model SFL-CPD20-Y
Basic parameters Navigation type Laser SLAM Navigation
Basic parameters Applicable Pallet Types Open pallets / Closed pallets / Shelves / Material cages
Basic parameters Rated load capacity 2000 kg
Basic parameters Load center distance 500 mm
Basic parameters Total vehicle weight (including battery) 3130 kg
Basic parameters Standard lifting height 3000 mm (customizable up to 4000 mm)
Basic parameters Vehicle dimensions (length x width x height) 2782 x 1180 x 2095 mm
Basic parameters Fork dimensions (length x width x height) 1070 x 122 x 40 mm
Basic parameters Fork width adjustment range 400mm ~ 700 mm
Basic parameters Minimum turning radius 1597 mm
Performance parameters Maximum driving speed when fully loaded/unloaded 1.5 m/s
Performance parameters Climbing ability / Obstacle clearance height / Gap width ≤5% / 10 mm / 30 mm
Performance parameters Navigation position accuracy / Navigation angle accuracy ±10 mm / ±1°
Battery parameters Battery Specifications 24 V / 200 Ah (Lithium iron phosphate battery)
Battery parameters Overall battery life 6 h ~ 8 h
Battery parameters Fast charging time (10% to 80%) 2 h
Battery parameters Charging method Automatic charging / Manual charging
Functional Configuration LiDAR quantity 1 main LiDAR + 3 auxiliary LiDARs
Security Configuration Laser obstacle avoidance protection range 360-degree all-around protection (40m detection distance)
Security Configuration Emergency braking distance (at speeds of 1.0 m/s and 1.5 m/s) ≤30 cm / ≤50 cm

Automated Guided Forklift Contrast
Point

SEER Robotics' automated guided unmanned forklift is based on a powerful core controller developed independently, which deeply integrates traditional scattered chassis control, visual recognition, and path planning algorithms to realize unified and efficient management of robot hands, eyes, and feet. Compared with the same type of products, it not only greatly reduces the width of the car body in the mechanical structure but also has a strong openness and interconnection ecology at the software level.

Lorem ipsumLorem ipsumLorem ipsumLorem ipsumLorem ipsumLorem ipsumLorem ipsumLorem ipsumLorem ipsumLorem ipsumLorem ipsumLorem ipsumLorem ipsum Lorem ipsumLorem ipsum
Solve the collaboration conflict that multiple models are isolated from each other and cannot be uniformly scheduled across processes
SEER Robotics, the software of the automated guidance unmanned forklift collaboration system, realizes the unified group control of multiple models such as unmanned forklifts, material box robots, and latent AMRs and solves the transshipment conflict between regions and processes.
To solve the problem of long time-consuming traditional mapping and equipment loss and positioning caused by environmental changes in the factory area
Using advanced laser SLAM trackless navigation and map update algorithms, there is no need to modify the physical environment of the site, and even if the goods stacking in the workshop changes, forklifts can still accurately locate and not get lost.
To solve the dumping and cargo damage accidents caused by the dislocation of goods in the docking of high-level stacking and warehouses
Through multi-sensor fusion and ultrasonic real-time status detection technology, the high-level shelves are accurately identified and aligned, avoiding the risk of cargo damage caused by blind spots.

Automated Guided Forklift Instructions

Digital environment mapping
Using supporting one-stop implementation tools, manual or remote control forklifts walking in the workshop, you can quickly build a high-precision laser SLAM environment digital map and automatically mark the shelves and charging pile positions.
01
Fork width and carrier configuration
According to the specifications of pallets, cages, or shelves used on-site, manually adjust the outer width of forks between 400 mm and 700 mm, and turn on the automatic pallet identification function in the control software to match the corresponding carrier type.
02
Automatic scheduling route and task assignment
Through the intelligent logistics management system or scheduling system to delimit the driving route, speed limit area, and obstacle avoidance trigger level, the forklift is connected to the warehouse management system of the factory, and the automatic distribution of tasks and cross-process transfer is realized.
03
Daily charging and power exchange maintenance
Set a low power threshold in the system, and the forklift will automatically drive to the charging station for fast charging when it is idle and the power is insufficient. In the case of heavy-duty continuous rotation, the lithium battery can also be quickly replaced manually within 2 min.
04

Automated Guided Forklift For People

3C Electronics and Semiconductor Manufacturing Plant Purchasing Director

This group has strict requirements for workshop cleanliness, channel narrowing, and fine control of equipment. This product with a narrow body and high-precision path planning is perfect to adapt to the intensive electronic production line material precision distribution.

Auto parts and heavy industrial manufacturing warehouse managers

This group faces the safety pain points of heavy materials, high handling frequency, and frequent man-machine mixing. This product provides a 2t large load, high endurance, and 4 layers of safety protection to ensure safe transportation of large, heavy industrial works.

Director of large-scale third-party logistics and e-commerce warehouse operations

This group is highly concerned about the utilization rate of warehouse space and high-density stacking efficiency. The forklift supports flexible intelligent identification and high stacking of pallets, cages, and other carriers, which can greatly improve the throughput capacity of vertical storage.

Technical Director of Transformation of Traditional Manufacturing Enterprises such as Pneumatic Component Processing

Such groups need to seamlessly connect automation equipment with existing WMS and MES systems. Relying on a powerful and open system software architecture, the product can quickly complete the integrated deployment of software and hardware, and is the core choice of factory digitization.

Certificates And Factories

证书大图

As the world’s leading controller manufacturer, SEER Robotics has independent intellectual property rights of SRC series controllers and production lines. It is the real source manufacturer, providing you with highly competitive ex-factory prices and faster delivery speed. Products comply with international standards and have been deployed in many countries and regions around the world. Through standardized communication protocols, the stable operation and technical compatibility of the system in multinational plant projects are ensured.

证书小图

FAQ

Q: Does this automated guided unmanned forklift need to change the existing factory or warehouse environment?
A: No. It uses advanced laser SLAM navigation technology to build maps and achieve accurate positioning by scanning the natural environment of the workshop. It does not need to lay magnetic strips on the ground, use magnetic nails, or stick reflectors on the wall to achieve efficient deployment.
Q: How does the 1180 mm narrow body ensure stability when carrying 2 t heavy objects or stacking them in high positions?
A: The forklift adopts a counterweight compact structure design, and the counterweight is optimized through precise center of gravity simulation. At the same time, the forklift has a built-in chassis inclination sensor and a height protection system, which will automatically limit the speed during heavy load or high stacking to ensure a stable overall center of gravity.
Q: How to solve the problem of traffic conflicts between multiple forklifts or different types of robots in the same workshop?
A: The unmanned forklift can be perfectly connected to the robot management system. The system can carry out unified group control scheduling, dynamic path planning, and intersection control for hundreds of multi-model robot fleets and completely avoid traffic congestion.
Q: If there are often people walking around in the factory workshop, how to ensure the safety of employees when the forklift is driverless?
A: The forklift has a 4-layer safety protection system, including a 3D obstacle avoidance laser with a 40m detection range and a full range of safe touch edges. When the system detects a pedestrian or obstacle ahead, it will decelerate step by step and trigger emergency braking within a safe distance, and the braking distance is extremely short.
Q: Can the equipment automatically identify and carry those with no fixed placement, the position of a slight deviation of the tray?
A: Yes. Forklifts are equipped with pallet recognition and intelligent vision algorithms as standard. Even if there is a certain degree of angular or linear deviation in the placement position of pallets on-site, forklifts can autonomously adjust the angle and posture of forks when approaching pallets to realize accurate fork-taking.
Question: What is the battery life and charging performance? Which charging modes are supported?
Answer: Using high-quality 24V/200Ah lithium iron phosphate batteries, long cycle life. It supports manual charging and automatic charging mode; in the fast charging state, 2h can be fully charged, and comprehensive endurance can reach 6h to 8h, fully meeting the high-intensity operation requirements of modern factories.
