SEER OneFork 300

SOF-300EU
SOF-300EU

CE Safety Certification, Flexible and Efficient

icon

CE Certification, Safety Guaranteed

The robot has passed the CE certification (ISO3691-4:2023) and other related certifications, ensuring safer operation.

icon

500mm Width, Designed for Narrow Aisles

The robot width is 500 mm, and the rotation radius is 800 mm, perfectly suited to narrow aisle scenarios. The ground clearance of the robot chassis is a mere 20 mm, enabling it to effortlessly pass through scenes like elevators.

icon

AI Carrier Recognition, Precise and Efficient

Equipped with a depth recognition camera, it supports real-time AI carrier recognition. Even in scenarios where the cargo is placed on a tote dolly without fixed grooves and the QR code, the robot can still precisely and efficiently pick up and drop off goods.

icon

Modular Design, Flexible Customization

The modular design and assembly enable the customization of the size of the forks and the robot based on demand. It is capable of adapting to various scenarios and meeting different demands.

icon

Multiple Sensors, 360° Safety Assurance

Built-in safety obstacle avoidance lasers, bumper strips, and photoelectric sensors, among various multiple safety sensors, providing 360° safety protection.

Product Parameters

rated-load

300

Rated Load Capacity (kg)
runtime

6

Comprehensive Battery Life (h)
max-lifting-height

70±5~90±5 (default 70)

Standard Lifting Height (mm)
minimum-turning-radius

800

Minimum Turning Radius (mm)
positioning-accuracy

±10, ±1

Positioning Accuracy (mm,°)
navigation-speed

0.8 / 1.4

Driving Speed (Full load / No load) (m/s)
● Standard    ○ Optional    - None
Product model

SOF-300EU

dom-icon
Product name

SEER OneFork 300

Operation type

Automatic navigation

Navigation type

Laser SLAM

Pallet type

Tote dolly / shelf

Rated load capacity

300 kg
(661.39 lbs)

Load centre distance

415 mm
(16.33 in)

Weight (with battery)

270 kg
(595.25 lb)

Standard lifting height

70±5 mm~90±5 mm (default 70 mm)
(2.76±0.20 in ~ 3.54±0.20 in(default 2.76 in))

Forklift dimensions: L x W x H

1044 x 500 x 1753 mm
(41.10×19.68×69.02 in)

Fork dimensions: L x W x H

610 x 300 mm
(24.01×11.81 in)

Minimum turning radius

800 mm
(31.49 in)

Ambient temperature and humidity range

TEMP: 0℃ to 50℃ / RH: 10% to 90%, no compression, no condensation
(TEMP: 32°F to 122°F / RH: 10% to 90%, no compression, no condensation)

Driving speed: full load / no load

0.8 / 1.4 m/s
(1.79 / 3.13 mph)

Passability (slope / step / gap)

<3% / 2 mm / 5 mm
(<3% / 0.08 in / 0.20 in)

Navigation position accuracy

±10 mm
(±0.39 in)

Navigation angle accuracy

±1°

Battery specifications

48 V / 23 Ah (lithium iron phosphate)

Comprehensive battery life

6 h

Charging time (10% to 80%)

1 h

Charging method

Manual / Automatic

Lidar number

1+2

Wi-Fi roaming

●

3D obstacle avoidance

●

Pallet recognition

●

HMI display

●

E-stop button

●

Sound and light indicator

●

Braking distance: 1 m/s / 1.5 m/s

≤30 cm / ≤50 cm
(≤11.81 in / ≤19.69 in)

360° laser protection

●

Bumper strip

●

Fork height protection

●

ISO 3691-4

●

EMC

●

UN38.3

●

RED

●

Product model

SEER One Fork Truck
